Understanding Viking (3). Carbon Fixation on Mars

At the end of the previous Single Scoop, Norm Horowitz, Jerry Hubbard, and George Hobby were ready to fly to Mars their experiment (referred here as the HHH experiment) to detect the fixation of inorganic carbon (¹⁴CO₂ and/or ¹⁴CO) by Martian soils to give ¹⁴C-labeled “higher organics”, organic molecules with many C-C bonds. The biological premises for this experiment were indisputable, then and now:

• All life requires higher organic molecules, made from carbon atoms.

• ¹⁴CO₂ and ¹⁴CO are the major sources of carbon in the Mars near-surface environment.

• Thus, if Mars life exists at the Viking sites, it must make ¹⁴C-labeled higher organics from ¹⁴CO₂ and/or ¹⁴CO.

• This carbon fixation could be measured by measuring the amount of radioactive ¹⁴C in the Martian soil after exposing samples of that soil to ¹⁴CO₂ and/or ¹⁴CO for five days.

• As a detail, should Martian microbial carbon fixation follow chemistry in any way analogous to carbon fixation by Terran photosynthetic microbes, some fixation would be observed for a time even in the absence of light.

• However, as a control, no fixation should be seen in samples that had been sterilized by heating the soil to 170 °C, after which no biological activity was presumed to be possible.

• Very few non-biological processes convert ¹⁴CO₂ and/or ¹⁴CO into compounds that contain C-C bonds, and even fewer that contain C-H bonds.

The Carbon Assimilation Experiment as Done on Mars

The only challenge in executing this analysis came with the difficulty of counting ¹⁴C-radioactivity in a sample of soil. The difficulty arises because the soil absorbs the high energy electrons (often called “beta particles”) emitted from ¹⁴C-atomic decay before they can (efficiently) reach a detector.

Accordingly, HHH experiment used a (somewhat) complex workflow to get the ¹⁴C-atoms in higher organic molecules out of the soil and into a radiation detector. In detail, the workflow had these steps:

Step 1. A scoop of Martian soil was delivered to an enclosed chamber with a light bulb, delivered from Earth to make sure it did not emit harsh UV light that might create the false positive discussed in the previous Scoop.

Step 2. A mixture of ¹⁴CO₂ and ¹⁴CO gases brought from Earth was put into the chamber.

Step 3. The light was turned at temperatures that ranged from 8 °C to 26 °C.

Step 4. Any photosynthetic microbes in the soil were given 120 hours (5 days) to fix as much radioactive carbon as they could into higher organic molecules.

No water was added, avoiding an unnatural flood of water that might kill Martian microbes inexperienced to them. The experiment was entirely natural, except for the label, the exact illumination (about 20% of the intensity in the relevant wavelengths, the short wavelengths being cut off), a 28% higher CO₂ atmospheric pressure (from 7.6 millibar to 9.8 millibar), and a ~23 fold higher partial pressure of CO. Then:

Step 5. The soil sample was heated to 120 °C to vent the excess radioactive ¹⁴CO₂ and ¹⁴CO gas that had not been fixed, but possibly remaining adsorbed to the soil as ¹⁴CO₂ and/or ¹⁴CO, not fixed into higher organic molecules by Martian microbes. This heating was seen on Earth to leave most biological higher organics intact.

Now the experiment was ready to go look for the ¹⁴C-radiolabeled higher organics in the soil. Again, the next steps in the workflow were intended to get radiolabel in those bio-organics out of the soil and into a spot where the soil would not interfere with its detection, the workflow continued:

Step 6. The soil sample was heated further, this time to 635 °C. This was intended to fragment, or pyrolyze, the fixed non-volatile ¹⁴C-labeled higher organics to give smaller organic fragments that were volatile. These were analogous to the small organics that come out of burnt popcorn to give the familiar burnt popcorn smell.

Step 7. The ¹⁴C-labeled organic fragments were then trapped in the pores and channels of the Chromosorb-P^® brand of diatomaceous earth.

So now the ¹⁴C label from the fixed higher organics was safely out of the soil and bound as organic fragments to the Chromosorb-P ^®. So the problem now was to get those 14C-labeled organic fragments out of the Chromosorb-P ^® and into a detector.

For this purpose, the Chromosorb-P ^® was coated with copper oxide (CuO). At the low temperature where any ¹⁴C-labeled Mars-life-fixed organic fragments were absorbed by the Chromosorb-P ^®, copper oxide did nothing. However, when Chromosorb-P ^® is heated to 640 °C, the copper oxide should oxidize those ¹⁴C-labeled organic fragments to radioactive ¹⁴CO₂.

Now, the ¹⁴CO₂ does not stick to Chromosorb-P ^®. Thus, the ¹⁴CO₂ created from the ¹⁴C-labeled organic fragments would be blown out of the Chromosorb-P ^® and into a detector, where the energetic electrons released by ¹⁴C-radioactive decay would be counted, without interference from either the soil or the Chromosorb-P ^®.

This gives the last three steps in the workflow.

Step 8. Heat the Chromosorb-P^® with embedded copper oxide to 640 °C. This oxidized any trapped ¹⁴C-labeled organic fragments to ¹⁴CO₂.

Step 9. Blow the resulting ¹⁴CO₂ out of the Chromosorb-P^® into a radioactivity detector.

Step 10. By measuring the number of high energy electrons emitted from the ¹⁴CO₂ in the detector, quantify how much ¹⁴C had been fixed in the Martian soil by putative Martian microbes during the 5-day photosynthetic incubation.

A picture is worth 1000 words. So here it is.

Figure 1. Workflow of the Horowitz carbon fixation experiment. As an anomaly, a surprisingly large amount (in fact, 99%) of the total of the radioactivity remaining in the soil after the soil was heated at 120 °C, but released only at 635 °C, did not bind Chromosorb-P^® as organic fragments, but passed through the Chromosorb-P^® as if it were CO₂ (Horowitz et al., 1977)

The Carbon Assimilation Results on Mars

So, what was actually seen? The HHH team reported that they saw a significant amount of radioactive ¹⁴CO₂ released from the copper oxide-impregnated Chromosorb-P ^® upon high heating. This is Step 8 in the workflow. According to the experiment’s design, this ¹⁴CO₂ could have come only from organic molecule fragments released pyrolytically from the Martian soil. Those fragments could be radiolabeled only if they had come from ¹⁴C-labeled higher organic molecules that the soil had fixed using the radiolabeled ¹⁴CO₂ and/or ¹⁴CO gases that Viking had carried from Earth to Mars.

Under the terms of the experiment, Horowitz, Hobby, and Hubbard had discovered autotrophic Martian life.

Not a lot of ¹⁴C of the amount of radioactivity remaining in the soil after it had been heated to 120 °C ended up sticking to the Chromosorb-P ^®, being released after the Chromosorb-P ^® was heated to 640 °C, and being interpreted as arising from carbon fixation by Martian autotrophs. But the amounts of fixed ¹⁴C were substantially more than what scientists call “experimental error”. For those familiar with statistics, the three authors reported that this radioactivity was “three sigmas above background”. In other words, something in the Martian soil was converting significant amounts of ¹⁴CO₂ and/or ¹⁴CO into ¹⁴C-labeled organic matter.

Autotrophy on Mars. As we will discuss below, the amount of fixed ¹⁴C corresponded to the amount in ~3000 E. coli cells.

Some of this ¹⁴C fixation was also observed when the experiment was repeated, but this time without light. But carbon fixation by photosynthetic autotrophs on Earth occurs also in the dark, at least until the point where they run out of energy and need another dose of sunlight. This process is appropriately called “the dark reaction”.*

Another observation surprised the Viking team. The soil continued to fix ¹⁴CO₂ even after it had been heated to 90 °C. While the ability of Martian life to tolerate heating was not known, many Terran photosynthetic autotrophs die when heated at 90 °C. Including likely the plant on your windowsill. The putative Martian microbes seem to be especially tough.

In any case, stronger heating to 175 °C destroyed the ability of the Martian soil to fix ¹⁴C. That, the experimenters presumed, was hot enough to kill any microbe, Terran or Martian.

In short, under the terms of the experiment’s design, every detail of the results from the carbon fixation experiment was consistent with a Martian soil containing a photosynthetic autotroph. This Martian microbial “plant” appeared to be a bit more resistant to heat than we expect from our experience with Terran photosynthetic autotrophs. Otherwise, the results were the same.

The HHH team brushed away an anomaly

So far so good. But there was an anomaly. When the HHH team heated the Martian soil to 635 °C, they observed an unexpectedly large amount of radioactivity coming from the soil that did not stick to Chromobsorb-P^®. This anomalous result is highlighted in red in Fig. 1. And it was not a small amount of radioactivity. It was 99% of the radioactivity that remained in the soil after it had been heated to 120 °C, the blue step in Fig. 1. This radioactivity was interpreted to be ¹⁴CO₂.

But where did the ¹⁴CO₂ come from? Again, the Earth based experiment gave two possibilities. First, this could have been ¹⁴CO₂ absorbed to the alkaline soil. But the absorption must be sufficiently strong that the absorption would not have been reversed at 120 °C. It could not have been flushed out when the soil was heated to 120 °C in Step 5.

As a second possibility, this could have been a large amount of ¹⁴CO₂ emerging from the soil as the organic fragments were pyrolyzed, extracting oxygen from other organic fragments.

The HHH team saw this unexpected ¹⁴CO₂ released in Step 6 and remarked on it. They wrote (Horowitz et al., 1977):

“The lamp is then turned off, and the chamber is brought to 120 °C while the radioactive atmosphere is vented [Step 5 in the workflow]. The chamber is next heated to 635 °C to pyrolyze organic matter in the sample [Step 6]. The volatile products, together with a large amount of ¹⁴CO₂ and ¹⁴CO desorbed from the soil grains and walls of the chamber, are swept by a stream of He into a column packed with a mixture of 25% cupric oxide and 75% Chromosorb-P^® [Step 7]. The column, which operates at 120 °C, retains organic molecules larger than methane but allows all but a small fraction of the CO₂ and CO to pass into a radiation counter where their radioactivity is measured. This count is referred to as peak 1.”

The anomaly is in italics.

They called the radioactivity in the unexpected ¹⁴CO₂ and/or ¹⁴CO “Peak 1”. If you look at their data, this “Peak 1” was 100 times larger than Peak 2. Peak 2 was the radioactivity in ¹⁴CO₂ that was formed from organic fragments that stuck to Chromosorb-P ^®, and then produced by copper oxide oxidation.

In other words, 99% of the radioactivity counted in the radiation detector after Step 5 was anomalous. But the HHH team did not puzzle long over it. They simply stated that this material had been absorbed onto the soil grains and walls of the chamber.

In fact, the chamber walls likely had not absorbed ¹⁴CO₂ and/or ¹⁴CO at 120 °C when the instrument was tested pre-flight on Earth. The team would never have flown such a chamber.

Of course, the soil was a wild card, since the pre-flight experiments on Earth did not have access to Martian soil specifically. Thus, it remains an open possibility that alkali in the soil made carbonates and/or bicarbonates that gave the feared false positive.

So here we have an anomaly. A large amount of ¹⁴CO₂ and/or ¹⁴CO was allegedly sticking to the soil and chamber walls at 120 °C, and not flushed out in Step 5. And this is where we must close for the day. Tomorrow we will explain the how this anomaly was dismissed in real time, and how it might be interpreted today.

---

References

Horowitz, N. H., Hobby, G. L., & Hubbard, J. S. (1977). Viking on Mars: the carbon assimilation experiments. Journal of Geophysical Research, 82(28), 4659-4662

---

Posted with minor revisions by Jan Spacek 2/20/2026.

Spacek’s notes:

* Carbon fixation through atmospheric chemosynthesis is common in Earth’s cold deserts, at some locations the trace gas metabolism (not reliant on sunshine) is the main source of organic carbo in sparse cold soils. I personally believe that on Mars the photosynthesis is less likely than chemosynthesis – however, this was not known when Viking experiments were designed.
